Angle Measurer
GAM 270 MFL Professional

with 4 x battery (AA), accessory set

Angle meter and inclinometer with laser-accurate transfer

Print

Our service promise for professionals.
Extend the warranty of your power tools.
Register now!

Technical data

The most important data
Measurement range 0-270°
Measurement accuracy, angles ± 0.1°
Power supply 4 x 1.5V AA
Battery power, approx. 50 h
Automatic deactivation, approx. 30 min
Arm length 60 cm
Weight, approx. 1.7 kg

Advantages

Angle meter and inclinometer with laser-accurate transfer

  • Digital angle measurer and inclinometer in one
  • Calculates mitre angles without the need for accessories
  • Inclinometer with laser up to a range of 30 m

Functions

Laser warning notice 1:2015-05; 635 nm Laser warning notice
MTR1/MTR2 Automatic calculation of mitre angles at the press of a button
Measuring accuracy of angles ± 0.1° Measuring accuracy ± 0.1°
Measuring accuracy of laser ± 0.5 mm/m Measuring accuracy ± 0.5 mm/m
Measuring range of angles 0°–270° Angle measuring range 0°-270°
Measuring range of laser max. 30 m Measuring range maximum 30 m
Lock Function GAM Lock function for locking the angle measurer at a certain angle
Distance of laser to plane the tool is resting on Laser 30 mm above plane the tool is resting on
Hold Hold function for intermediate storage of measured values
Display lighting Illuminated display
IP protection 54 Dust and splash protection IP54
Flip Display Rotating readout on display

Prices / Package contents


with 4 x battery (AA), accessory set

Order number: 0 601 076 400

Selected version

Price includes:

  • Leg extension
  • Protective Bag
  • 4 x 1.5 V LR6 battery (AA)

Downloads

Product data sheet

GAM 270 MFL Professional
(approx. 1.5 MB)

Download
User Manual

GAM 270 MFL (PDF 26.8 MB)
